Hydraulic
The Wolfram Hydraulic library adds complete hydraulic functionality to Wolfram System Modeler's already powerful modeling capabilities. All common components such as valves, cylinders, pumps, tanks, accumulators and pipes can be connected in arbitrary hierarchical layouts. These components can also be used together with libraries in other domains, such as the automotive or aerospace fields.
Features
- Hierarchical and large-scale modeling of hydraulic systems
- Standard directional control, flow control and pressure control valves
- An extensive collection of cylinder configurations, pumps and motors, and tanks and accumulators, as well as pipes with laminar and turbulent flow
- Standard media components such as oil, water and air, as well as user-defined media
- Illustrative example models to demonstrate the use of the library
- A visual component design that conforms to the DIN ISO 1219 standard
- The possibility to combine components from the Hydraulic library with components from the Modelica Standard Library or libraries from other domains
Examples
Details
| Version | 2.0 | Platforms | All Platforms |
|---|---|---|---|
| Updated | January 2024 | Requirements | None |
| Size | <10MB | Language | English |
| Library Dependency | Modelica Standard Library 4.0.0 | Support | support@wolfram.com |
| System Modeler Compatibility | 14.0 | Documentation | Hydraulic Documentation |
| License | Wolfram System Modeler Library License |
