The Rotating Machinery library allows you to test novel designs or identify faults in rotating machinery such as turbines, motors and drivelines. Within the library, you'll find fundamental components of rotating machinery, such as gears, shafts and bearings. These components are designed to be flexible, enabling you to observe deformations and accurately capture real-world responses under different loads. By utilizing this library, you can explore and compare different designs to understand their effects, such as vibrations, deflections and contact stresses, among other things.

Features

  • Pre-configured high-fidelity models for bearings, gears, shafts, disks and supports
  • Parametrizable components to quickly test different designs
  • Built-in animation of all models, providing an easy visual check of your modeling process
  • Built-in example models that show the wide variety of systems that can be modeled with the library
  • Allows the combination of components from the Modelica Standard Library
